Semi-automatic Paraffin Microtome

The semi-automatic paraffin tissue microtome is a device for rapid pathological section analysis of human, animal, and plant tissues. It is widely used in hospitals, medical schools, forensic medicine, and animal/plant research institutions for pathological diagnosis, analysis, and research.

The machine primarily consists of four sections:
1. The upper section houses the microcomputer control unit, featuring a control panel, temperature display, and operational status indicators.
2. The middle section comprises the cryogenic chamber for rapid freezing of biopsy specimens and the sectioning operation area.
3. The lower section contains the compressor unit for refrigeration. 4. The rear section integrates the mechanical transmission and motor drive components.

• Color LCD touchscreen display shows total slice count and total slice thickness, slice thickness, specimen retraction value, temperature control, date, time, temperature, scheduled sleep mode on/off, manual and automatic defrost functions.

• User-friendly sleep function: When sleep mode is selected, the freezer compartment temperature automatically maintains between -5°C and -15°C. Upon exiting sleep mode, the cutting temperature is reached within 15 minutes.

• Temperature sensor self-check function automatically monitors sensor operational status.

• Dual compressors provide independent cooling for five zones: freezer compartment, freezer platform, blade holder, sample clamp, and tissue flattener.

• Blade holder features a color-coded blade pusher and protective guard covering the entire blade length for user safety.

• Configuration: X-axis 360°, Y-axis 12° universal rotation snap-on tissue clamp for faster tissue mounting.

• Anti-adhesion tissue flattener with refrigeration, reaching temperatures as low as -50°C, facilitating rapid tissue freezing and saving operational time.

• Single-layer heated glass window effectively prevents condensation.

• Handwheel positioning with 360° locking at any point.

• Disinfection method: UV ultraviolet sterilization.
