Food Mycotoxin Analyzer

Food Mycotoxin Analyzer

  • Product Number:LD-L1P
  • Product Difference:Single-channel detection, equipped with a constant-temperature incubator, mainly for detecting the content of fungal toxins in grain, oil, and feed

Product Introduction

The grain mycotoxin detector employs a fluorescent quantitative rapid detection principle, primarily used to measure mycotoxin levels in grain, oil, cereals, and feed, including aflatoxin B1, aflatoxin M1, zearalenone, vomitoxin, fumonisin, etc., as well as heavy metals in grains such as lead and cadmium. The testing samples include grains (rice, corn, wheat, barley, sorghum, etc.) and their products, feed and its raw materials, edible oils, milk and its products, etc.; Sample pretreatment is simple, and the entire testing process takes 12 minutes. The product is suitable for local grain warehouses, grain production enterprises, feed mills, various livestock farming enterprises, flour mills, food processing plants, third-party testing institutions, and government regulatory departments at all levels.

Product Features

  • High stability: Uses imported fluorescent microspheres with uniform particles, ensuring product stability from the source and good reproducibility within and between batches; the test strips can be stored at room temperature without refrigeration; after testing, the test strips can be dried and stored for one year, ensuring traceability of results; Equipped with a temperature-controlled device, one strip per well, automatic timing, unaffected by external temperature and humidity, suitable for a wider range of environments.

  • Rapid and accurate quantification: Combines the advantages of colloidal gold rapid testing, enzyme-linked immunosorbent assay quantification, and chromatographic accurate detection, achieving rapid and accurate quantitative testing.

  • Built-in quantitative standard curve: The instrument has a built-in standard curve, eliminating the need for standard samples. No standard curve needs to be created during testing, saving costs and preventing operators from coming into contact with vomitoxin, thereby protecting their safety.

  • On-demand testing: There are no requirements for the volume of testing samples. Samples can be tested on-demand, whether individually or in small quantities, or in large quantities simultaneously, and on-site testing is also possible.

  • Low requirements for supporting equipment: There are low requirements for supporting pre-processing instruments, equipment, and personnel. Operators can master the process with short-term training.

  • High cost-effectiveness: Achieve the quality and results of chromatographic testing at one-third the cost of imported equipment, while saving manpower and resources and significantly reducing testing costs.

  • Professional and hassle-free: Sample curves can be customized according to user needs, and remote operation is possible without the need to return the instrument to the factory.

Product parameters

Screen Size10.1-inch HD display, resolution 1280x800, memory 1+8GB
Operating SystemAndroid 7.1.1
Detection MethodReflective photodetection
Detection PrincipleFluorescent immunoassay
Card Holder Size70mm x 20mm
Unlock MethodPassword
LanguageChinese/ English
Storage Capacity100,000+
Detection ChannelSingle Channel
Detector/Light SourcePhotodiode, 365nm Light Source
Detection SpeedSingle Detection Time < 5 seconds, capable of performing fluorescent quantitative detection on samples

Detection Method

Automatic scanning
Card Insertion DetectionThe detection channel cannot perform detection if the detection card is not inserted
Built-in FunctionsBuilt-in quality control functions, including device calibration, device self-inspection, reagent card self-testing
Detection curveCan verify the detection results of the reagent card to prevent misjudgment
Project managementSupports expansion of detection project functionality
Interface settingsCan modify the title and footer information, flexibly display instrument information
PrinterThermal printer (thermal paper: 57x30mm)
Data transmissionWiFi, Bluetooth, USB, RF card reader, barcode scanning module
Data ProcessingData aggregation and upload to the regulatory platform via communication ports, etc.
Constant Temperature Incubator8-channel independent control, automatic timing upon insertion, and capable of incubating 1.5ml sample tubes
AccuracyError value ≤ 5%

Stability

SW (coefficient of variation) ≤ 5%
RepeatabilityCV (coefficient of variation) ≤ 3%
Resolution0.001
Interfaces2 USB ports; 1 USB-B port; 1 LAN port; 1 DC power port (5.5/2.1mm)
Power SupplyInput: AC 100V-240V/1.3A, 50Hz; Output: DC 12V/5A
Operating EnvironmentTemperature: 0~50°C, Humidity 0~90%
Dimensions and Weight300 x 235 x 125 mm, 2.2 kg
Accessory Case740 mm × 490 mm × 310 mm precision instrument carry case, military-grade shockproof/IP54 waterproof, silent swivel wheels + aviation-grade aluminum alloy, lightweight design for enhanced portability
