Food Testing Sample Preparation Machine

Food Testing Sample Preparation Machine

  • Product Number:LD-QC5A
  • Product Difference:A five-in-one device for sample concentration, water bath temperature control, centrifugal stratification, homogenization, and oscillation mixing, equipped with 10mL centrifuge tubes

Product Introduction

A new type of instrument developed independently—the food testing sample pretreatment integrated machine. The sample pretreatment integrated box integrates the equipment required for sample concentration, water bath temperature control, centrifugal stratification, homogenization, and shaking mixing during the sample pretreatment process. Only one sample pretreatment integrated box is needed to complete the entire sample pretreatment process, and it is easy to carry. It is not only suitable for on-site testing but also for the purification and preparation of samples for chromatography, mass spectrometry, and other analyses.

Product Features

  • Compact design integrates five commonly used sample pretreatment functions, enabling one-stop sample processing.

  • Sturdy construction with a high-quality engineering plastic chassis that offers excellent impact resistance, corrosion resistance, and portability.

  • Stable operation, featuring a 5-inch full-color LCD screen with clear functional indicators. All user operations are performed via physical switches, eliminating the risk of operational failure when wearing gloves or in the presence of liquid splashes.

Product parameters

Centrifugation FunctionMaximum Speed4500 rpm (revolutions per minute)
Maximum Relative Centrifugal Force2200 (×g)
Angular Rotation Capacity10 ml x 6
Oscillation mixing functionOscillation mixing speed3000 rpm (revolutions per minute)
Operating modeContinuous
Speed control methodStepless speed control
Homogenization and grinding functionMotor speed15000 rpm (revolutions per minute)
Blade material304 stainless steel three-dimensional blades
Cup body materialABS
Concentration drying function (with heating module)Heating air holes12 holes
Air sourceA: Air (high-performance air compressor), B: Nitrogen Compatible
Temperature Deviation≤±0.5℃
Carrier Gas Flow Rate36L/min
Heating RangeRoom Temperature to 100℃
Water bath heatingHeating rangeRoom temperature to 100°C
Internal maximum dimensions150mm x 140mm x 100mm
Includes stainless steel stand
