Capsaicin detector

The capsaicin detector is primarily used for measuring natural capsaicin in various chili peppers and chili pepper products. The instrument consists of a brightness-emitting diode light source, a colorimetric cell, a high-sensitivity integrated photodiode, a microprocessor, a large-screen LCD display with Chinese characters, and an embedded miniature thermal printer integrated chip. It can directly display the content of relevant indicators in the tested sample on the large-screen LCD display, print the analysis results, and transmit data to a computer via a computer interface for data analysis.

The capsaicin components in the sample react specifically with a color reagent under certain conditions, producing products of varying color intensity. These products selectively absorb visible light of different wavelengths, and the depth of color (i.e., the absorbance) correlates with the concentration of the indicator component in the sample. Within an appropriate concentration range, this relationship follows the Lambert-Beer law. Therefore, the absorbance values measured by the instrument are automatically calculated using the built-in standard curve software to determine the accurate concentration of the indicator component in the sample and whether it exceeds the limit.

• Built-in embedded system, no external computer required for operation, storage, and printing.

• Full-screen display of 96-well plate data, intuitive visual plate layout interface.

• Convenient touchscreen input, with optional external mouse and keyboard.

• Plate layout and save/import functions significantly improve testing efficiency for commonly used projects.

• Measurement modes: single-wavelength detection, dual-wavelength detection, two-point method, kinetic method, enzyme inhibition rate, endpoint method, and rate method.

• Up to 12 different projects can be tested on the same plate, and both qualitative and quantitative projects can be tested on the same plate.

• Calculation methods include absorbance, Cut-Off qualitative calculation, single-point calibration, linear regression, exponential regression, logarithmic regression, double logarithmic regression, log-logit, power regression, four-parameter regression, and enzyme inhibition rate.

• Comprehensive quality control functions, including Westguard multi-rule quality control, instant method quality control, and various quality control charts and parameter calculations, with quality control alarm functionality.

• Flexible qualitative formula input functionality to accommodate different parameter settings for various reagents.

• Optional external PC software support, network-enabled, aligned with digital development trends, and customizable for uploading.

• New-style color graphical interface, fully Chinese-language operating system, supports mouse, keyboard, and input methods.

• Dedicated system maintenance menu, automatically assesses the instrument's current status and performance metrics, and can print related data.

• Intelligent light source on/off function to extend its lifespan.

• Multiple printing options and various formats of Chinese reports are available, with customizable report templates.
