Single-Layer Smart Constant-Temperature Shaking Incubator

Product Introduction

Single-Layer Smart Constant-Temperature Shaker is a new generation (large LCD multifunctional combination shaker).

User-friendly visual interface, intuitive and easy to understand.
Low-pressure safety control throughout, ensuring comprehensive protection.
Openable ventilation system, providing fresh air and oxygen on demand.
High-gloss mirrored inner chamber, simplifying sterilization.
Visual insulation glass for clear visibility of internal conditions.
Stackable design for enhanced experimental convenience.
Robust all-metal exterior for reliable load-bearing.
High-load, long-life transmission system for assured performance.
Automatically stores operating parameters for USB drive retrieval.
Segmented programming with automatic lighting and temperature control allows flexible parameter combinations.
Refrigeration system utilizes imported compressor units and R-134A imported eco-friendly refrigerant for safe and environmentally conscious operation.

Technical Specifications	Multifunctional Combination Shaker
Oscillation Frequency	20~300 rpm (same per layer)
Amplitude	26mm
Maximum Capacity (Single Layer)	2000ml*15 or 1000ml×24 or 500ml×40 or 250ml×60 (Fixed Fixture)
Standard Configuration	Universal Spring Rack
Tray Dimensions (mm)	Single Layer 900×540 (Three-layer combination)
Timing Range	0~9999 minutes/hours (Multi-stage timing available)
Temperature Control Range	4℃~60℃ (At ambient temperature 23~25℃)
Temperature Accuracy	±0.1℃
Temperature Uniformity	±0.5℃
Display Method	LCD (Touchscreen)
Input Power	Single Layer: 1600W
Dimensions (mm)	1400×850×1960 (mm) (Three-layer)
Weight	720kg
Control Method	Microcomputer Intelligent Control
Door Opening Method	Electric Door
Volume	240L
